Lockbro Drive 500 Gate Motor

Description

Key Features:

• High-speed motor with removable brushes for long-term serviceability

• Advanced control panel with backlit LCD display for easy setup, fault diagnostics, and adjustments

• Battery backup ensures reliable operation during power outages

• Built-in ET Blu Mix® receiver with 1000-user capacity and rolling code security

• Secure access with pin-code lockable programming and tamper monitoring

• Supports heavy-duty security brackets for added physical protection (optional)

• Suitable for gates up to 500kg and 5m in length

• Rated speed of up to 28m/min (depending on load and battery status)

• Alarm inputs for safety beam tampering and gate-forced-open events

• Supports solar charging integration (via optional accessories)

Technical Summary:

• Power Supply: 230V AC (with battery power: 12V 7.5Ah)

• Max Gate Weight: 500kg

• Max Duty Cycle: 25% (on mains)

• Receiver Frequency: 434MHz

• Memory Capacity: 1000 users

• Battery Operations: ±100 cycles in 24h without mains

• Security Functions: Alarm monitoring, RF jamming detection, programmable lockout

• Compatible Accessories: ET transmitters, solar kits, loop detectors, wireless keypads
